“Layouts for the Layperson”

Ditch the bloated CAD tools. Simply import your floorplan and custom device library to drop hardware, route connections, and validate your lighting control layouts in record time.

SystemDraft is a powerful, offline-first layout and engineering platform designed for lighting control professionals. Built to be completely manufacturer-agnostic, it empowers designers to import floorplans, route intelligent 2D topologies, and automatically validate electrical loads. From real-time engineering audits to instant, room-by-room Bills of Materials, SystemDraft turns complex system designs into verified submittals and quick quotes in record time.
